Транспортер 059K37912 для Xerox Phaser 7760 (Код: 49963)

Транспортер 059K37912 для Xerox Phaser 7760

059K37910, 059K37912, 059K37915, 059K37916, 059K37917, 059K37918, 059K37919, 059K71030, 059K71031, 059K71032, 059K71033, 059K71034, 059K71035, 059K71036, 059K71037, 059K71038

PL 21.23 Booklet Tray Component
Item Part Description
1 050E19900 Tray
2 – Upper Tray (Not Spared)
3 – Bracket (Not Spared)
4 127K38050 Tray Belt Drive Motor
5 – Bracket (Not Spared)
6 – Spring (Not Spared)
7 – Gear Pulley (Not Spared)
8 – Roll (Not Spared)
9 – Belt (Not Spared)
10 – Pulley (Not Spared)
11 – Bearing (Not Spared)
12 – Roll (Not Spared)
13 – Shaft (Not Spared)
14 – Shaft (Not Spared)
15 130K64300 Booklet No Paper Sensor
16 – Bracket (Not Spared)
17 – Actuator (P/O PL 21.23 Item 21)
18 – Spring (P/O PL 21.23 Item 21)
19 – Bracket (Not Spared)
20 – Lower Tray (Not Spared)
21 604K13840 Actuator Assembly

PL 21.24 H - Transport: 1 of 4
Item Part Description
1 – H - Transport Center Tray (Not
Spared)
2 022K71111 Pinch Spring Assembly
3 022K71121 Pinch Spring Assembly
4 – Upper Decurler Cover (Not Spared)
5 – Harness Assembly (Not Spared)
6 – Decurler Cover (Not Spared)
7 – Cover (Not Spared)
8 003E61620 Knob
9 – Top Exit Cover (Not Spared)
10 – Latch Bracket (Not Spared)
11 110K12282 Interlock Switch
12 113E20900 Interlock Switch Harness

PL 21.25 H - Transport: 2 of 4
Item Part Description
1 022K67641 Decurler Roll
2 031E94651 Decurler Arm
3 008E94070 Decurler Cam
4 007K89451 Gear (20T)
5 807E08980 Gear
6 604K25210 Knob Gear
7 130K88780 H - Transport Interlock Sensor
8 130K88291 H - Transport Entrance Sensor
9 012E12110 Guide
10 121K34421 Gate Solenoid
11 – Solenoid Bracket (Not Spared)
12 – Solenoid Cover (Not Spared)
13 020E37490 Pulley (18T)
14 423W26754 Exit Drive Roll Belt (67T)
15 012E12170 Gate Link
16 130E88350 Center Tray Exit Sensor
17 050E89621 Entrance Gate
18 130K87970 H - Transport Exit Sensor

PL 21.26 H - Transport: 3 of 4
Item Part Description
1 121K24610 Decurler Cam Clutch
2 008E94070 Decurler Cam
3 – Decurler Arm (Not Spared)
4 – Bushing (Not Spared)
5 020E37480 Pulley (20T)
6 423W27854 H - Transport Motor Belt (78T)
7 807E08600 Gear (20T)
8 – Cover (Not Spared)
9 127K40051 H - Transport Drive Motor
10 130K88780 Decurler Cam Sensor
11 807E04000 Gear (24T)
12 – Shaft (Not Spared)
13 – Pin (Not Spared)
14 807E04010 Gear (20T/24T)
15 120E20690 Sensor Flag
16 007K89440 One Way Gear (18T)

PL 21.27 H - Transport: 4 of 4
Item Part Description
1 121K35313 Tray Nip Solenoid (P/O PL 21.27
Item 20)
2 – Pin (P/O PL 21.27 Item 20)
3 – Tray Nip Link (P/O PL 21.27 Item
20)
4 – Support Bracket (Not Spared)
5 – Bracket (Not Spared)
6 022K67631 H - Transport Drive Roll
7 020E37750 Pulley (26T)
8 020E37440 Pulley (18T)
9 020K10760 One Way Pulley
10 022E27700 Idler Roll
11 022K67652 Exit Drive Roll
12 423W88254 H - Transport Drive Belt (450T)
(REP 12.66)
13 020E37460 Gear Pulley (40T/26T)
14 – Spring (Not Spared)
15 809E56092 Pinch Roll Spring
16 013E26740 Bushing
17 022E27750 Exit Pinch Roll
18 054E26112 Upper Exit Chute
19 – Pinch Roll Shaft (Not Spared)
20 121K35312 Tray Nip Solenoid Assembly
21 – Bracket (Not Spared)

----------------
Предназначено для работы в следующих моделях :
Xerox Phaser 7760

---------------+//
Деталь с разбора. Работоспособность проверена. Гарантия при установке в сервисном центре - неделя.
